Audison APK165 – 16.5cm Prima component speakers

Two way system features AP 1 tweeter and AP 6.5 Woofer. APCX TW crossover features a two-position level selector providing the ability to adapt its response to its two main applications: 2dB if installed behind the OEM grille, 0dB for an A-pillar installation without additional grilles between the tweeter and the listener. To ease the installation in OEM placements the woofers are equipped with high current fast-on terminals with double contact on positive and negative poles for high flexibility and quick connection. 1 AP1 tweeter with 26 mm diameter diaphragm combined with a wide-roll surround provides maximum efficiency and reduced resonance frequency. 2 AP 1 tweeter with acoustic lens designed to compensate for and fine tune the in-car frequency response anomalies in the 10kHz-13kHz bandwidth caused by restrictive OEM grilles in critical OEM placements. 3 APCX TW very compact tweeter passive crossover optimised for OEM Integration featuring an attenuation switch (0 dB, 2dB) to tune the in-car response according to different installation conditions. 4 Passive crossovers are supplied with “OEM Integration compliant” fast-on connectors. The ends, different in each of the two poles, eliminate any possible connection errors and speed up the required installation time. 5 AP 6.5 woofer with 32 mm pure copper voice coil, for high power handling and outstanding low frequency control. 6 AP 6.5 woofer with water-repellent treated paper cone, featuring a profile developed with FEM (Finite Element Method) simulation technology and optimized with the Klippel R&D Scan Vibrometer. 7 AP 6.5 woofer with reduced mounting depth, providing ease of installation in OEM placements. 8 AP 6.5 woofer with TPU (Thermoplastic Polyurethane) surround, featuring the exclusive shallow “Triple Wave” profile, for maximum excursion linearity. 9 AP 6.5 woofer with compact basket, protected by abrasion-resistant and scratch-proof coating, the motor affixed with damping epoxy adhesive. 10 AP 6.5 woofer with high current fast-on terminal with double contact on positive and negative poles for high flexibility and quick connection. The terminal features a temperature resistant plastic cover, protecting it against accidental short circuits. 11 Developed with the KLIPPEL suite. * Grille included TECHNICAL SPECIFICATIONS Component 2-way Coaxial Size mm (inch) Woofer 165 (6.5) / Tweeter 26 (1) Power Handling Peak 300W / continuous 100W Impedance 4Ω Frequency Response Hz 60 ÷ 20k Crossover type HP @ 3,5 kHz – 6 dB Oct Component adjustment dB 2; 0 Magnet size mm 85 x 40 x 15 D x h (in.) (3.35 x 1.57 x 0.59) Weight of one speaker kg (lb) Woofer 0,78 (1,72) / Tweeter 0,04 (0,09) Voice Coil Ø mm (in.) Woofer 32 (1,26) / Tweeter 20 (0.8) Kit includes 2 x 6.5″ woofers, 2 x tweeters, 2 x crossovers
