Audison BIT NOVE DRC – THE NEW AUDISON BIT PROCESSOR

bit Nove is a powerhouse of technology fully dedicated to listening pleasure: since 2007, the year in which the bit One was first introduced, Audison has never stopped delivering innovation to the digital processors segment. The bit Nove was born from this unique know-how within the industry, the perfect tool to expand a car audio system maximizing its performance. Input Connectivity Equipped with 6 high (3 ÷ 20V) and low (1.2 ÷ 8V) level inputs, the bit Nove can be used with any type of aftermarket and OEM source. The auxiliary RCA input (0.3 ÷ 5V) is perfect to connect your smartphone or tablet to the bit Nove providing the highest possible quality. The advanced PC software sums up the channels belonging to the same front and de-equalizes the OEM source frequency response in a few simple steps. There are also two optical digital inputs with a maximum accepted resolution of 192 kHz/24 bit to simultaneously connect an Audison bit DMI to the bit Nove (taking the digital audio from the car MOST bus) and the Hi-Res bit Play HD player. USS – Universal Speakers Simulator Thanks to the integration of the USS technology, the bit Nove can also be connected to headunits featuring the “speaker load detection” circuit that would otherwise mute the audio signal output. Output Connectivity The bit Nove features nine output channels on RCA connectors providing a large number of active multi-amplified configurations, ensuring a wide range of set-up options to the installer. For each channel, the powerful DSP provides: a 10-pole parametric equalizer allowing for optimal adjustments, a 68 steps frequency crossover, Butterworth or Linkwitz-Riley type filters with slopes from 6 to 24 dB/Oct and a time-delay line Power Supply Voltage: 10.8 = 15VDC Operation Power supply Voltage: 7.5 – 14.4VDC Idling Current: 0.53 A Switched off without DRC: 1mA Switched off with DRC: 4.5mA Remote in Voltage: 4 = 15 VDC (1mA) Remote Out Voltage: 10 = 15 VDC (130mA) ART (Automatic Remote Turn ON): 2 = 7 VDC Signal Stage Distortion – THD @ 1kHz, 1 VRMS Output: 0.005% Bandwidth @ -3 dB: 10 Hz = 22 kHZ S/N Ratio @ A Weighted Master Input: 102 dBA AUX Input: 101.5 dBA Optical In1/In2 inputs: 110 dBA Channel Separation @ 1 kHZ: 85 dBA Input Sensitivity Pre Master: 1.2 = 8 VRMS Input Sensitivity Speaker Master: 3 = 20 VRMS Input Sensitivity Aux Master: 0.3 = 5 VRMS Input Inpedance Pre In / Speaker In / Aux: 15 KOhm /12 Ohm/ 15 KOhm CAS Technology Max Output Level (RMS)@ 0.1% THD Input Stage Low Level (Pre): Ch1 = ch6; AUX/L/R High Level (Speaker In): Ch1 = Ch6 Digital: 2 x Optical S/PDIF; Max 192 kHz / 24 bit Output Stage Low Level (Pre): Ch1 = Ch9 Connection From / To Personal Computer: 1 x Micro USB To Audison DRC AB / DRC MP: 1 x AC Link Optical 2 Sel: Optical in 2 wire control = 12 v enable Mem D Sel: Memory D wire Control GND enable Crossover Filter Type: Full / Hi Pass / Low Pass / Band Pass Filter Mode & Slope: Linkwitz @ 12/24 dB – Butterworth @6/12/1/24 dB CAS TecH Corssover Freq: 68 Steps @ 20 = 20k Hz Phase Control: 0* /180* Equalizer (20 = 20k Hz) Analog Input Equalizer: Automatic De-Equalization Output Equalizer: N.9 Parametrics Eq : 12dB; 10Pole; 20=20k Hz Time Alignment Distance: 0 = 510cm / 0 = 200.8 Inches Delay: 0 = 15 ms Step: 0,08ms; 2,8 cm / 1.1 inches Fine SET: 0,02ms; 0,7 cm / 0.27 Inches General Requirements PC Connections: USB 1.1 / 2.0 / 3.0 Compatible Software/PC Requirements: Microsoft Windows (32/64 Bit) Vista, Windows 7, Windows 8, Windows 10 Caraudiosecurity Technology Video Resolution with Screen Resize: Min 1024 x 600 Ambient Operating temp. Range: 0 *C to 55 *C (32 *F to 131 *F) Size Diemensions (WxHxD): 130 x 34.5 x 199 (5.11″ x 1.35 “x7.83” Weight (Kg/Ib): 0,7/1.5
