Audison Prima AP4 D – 4 Channel Amplifier Bridgeable Amp

FEATURES Distortion – THD @ 1 kHz, 4 Ω, 90% Output Power: 0.01% Bandwidth @ -3 dB, 2 V RMS, 4Ω: 10 ÷ 30k Hz S/N ratio @ A weighted, 1,5V, Max Power: 100 dBA Damping factor @ 1 kHz, 2 VRMS, 4 Ω 170 Input sensitivity PRE IN: Selectable: 1,5 – 3 – 4,5 V RMS Input sensitivity SPEAKER IN: Selectable: 3 – 6 – 9 V RMS Input impedance: 15k Ω LOAD IMPEDANCE (MIN): 4 Ch: 1-2-3-4: 2Ω 2 Ch: Bridge (1-2) (3-4): 4Ω MAX POWER: 520 W OUTPUT POWER (RMS) @ 14.4 VDC, 1% THD: 4 Ch @ 4Ω: 70 W x 4 4 Ch @ 2Ω: 130 W x 4 2 Ch – (Bridge 1/2; 3/4) @ 4 W : 260 W x 2 OUTPUT POWER (RMS) @ 14.4 VDC, 10% THD: 4 Ch @ 4Ω: 90 W x 4 4 Ch @ 2Ω: 180 W x 4 2 Ch – (Bridge 1/2; 3/4) @ 4 W : 360 W x 2
